| Parameter | VS135 | VS125/VS125-LW | VS126 |
|---|---|---|---|
| Install Range | Standard Version: Up to 3.5m High Ceiling Mount: Up to 6.5m |
VS125: 2.2m-6m VS125-LW: 1.9m-3.5m |
6m-15m |
| Detection Distance | Standard Version: 4.14m × 3.02m, installed at a height of 3.5m 98° H, 80° V High Ceiling Mount: 5.54m × 3.98m, installed at a height of 6.5m 60° H, 45° V |
VS125: FoV: 101° H, 70° V Detection Area: Range from 1.21m × 0.7m at the installation height of 2.2m to 10.44m × 6.02m at a installation height of 6m VS125-LW: FoV: 130° H, 117° V Detection Area: Range from 0.86m × 0.65m at the installation height of 1.9m to 7.71m × 5.87m at a installation height of 3.5m |
FoV: Up to 75.4° Horizontal, 57.4° Vertical 10.40m × 7.80m @10m Installation Height |
| Radar Sensor | √ | / | / |
| 3-Axis Sensor | √ | √ | √ |
| Temperature | / | / | / |
| LoRaWAN® | √ | / | / |
| Ethernet (PoE) | √ | √ | √ |
| Cellular | √ | √ | √ |
| Wi-Fi HaLow | √ | / | / |
| Wi-Fi | √ | √ | √ |
| DI/DO | √* VS135 (PoE) Only | √ | √ |
| Serial Port | / | √ | √ |
| Button | 1× Reset/Wi-Fi Button | 1× Reset/Wi-Fi Button | 1× Reset/Wi-Fi Button |
| LED Indicator | √ | √ | √ |
| Configuration | VS135 (LoRa): Wi-Fi VS135 (PoE): Ethernet+Wi-Fi VS135 (Wi-Fi HaLow): Wi-Fi VS135 (Celluar): Wi-Fi |
VS125/VS125-LW (Cellular): Wi-Fi VS125/VS125-LW (PoE): Ethernet & WiFi |
Cellular: Wi-Fi PoE: Ethernet & WiFi |
| Data Storage | 1000000 sets | 1000000 sets | 1000000 sets |
| Data Retransmission | Except VS135 (LoRa) | √ | √ |
| Milesight D2D | / | / | / |
| Milesight IoT Cloud Management | √* VS135 (LoRa) Only | / | / |
| DeviceHub Management | √* For VS135 (Celluar, Wi-Fi HaLow, PoE) | √ | / |
| Milesight Development Platform | √ | √ | √ |
| Power Supply | VS135 (PoE): 802.3at PoE+ or DC 12V/2A VS135 (Celluar/Wi-Fi HaLow/LoRa): DC 12V/2A |
VS125/VS125-LW (PoE): 802.3af PD or DC 12V/1A VS125/VS125-LW (Celluar): DC 12V/1A |
PoE: 802.3af PoE or DC 12V/1A Cellular: DC 12V/1A |
| Dimensions (mm) | 200 × 35 × 85 | 185 × 85 × 34 | 435 × 75 × 38.5 |
| Operating Temperature | -20°C~50°C | VS125: -20°C~50°C VS125-LW: -20°C~60°C |
-20°C ~ 60°C |
