The UG67 is an industrial outdoor LoRaWAN gateway connecting 2,000+ nodes across 15 km for smart agriculture, metering, and industrial IoT. Multiple backhaul backups with Ethernet, 4G LTE, and Wi-Fi, built-in network server, and compatibility with TTN, ChirpStack, AWS, BACnet, and Modbus simplify deployment and integration.
Product Features
| CPU | Quad-core 1.5 GHz, 64-bit ARM Cortex-A53 |
| Memory | 512 MB DDR4 RAM |
| Flash | 8 GB eMMC |
| LoRa Channels | 8 (Half/Full-duplex) |
| Frequency Bands | CN470/IN865/EU868/RU864/US915/AU915/KR920/AS923-1&2&3&4 |
| Sensitivity | -140 dBm @ 292 bps |
| Tx Power | 27 dBm Max |
| Ethernet | 1× RJ45 WAN (10/100/1000 Mbps, PoE PD supported) |
| Wi-Fi | IEEE 802.11 b/g/n, 2.4 GHz, internal antenna |
| Cellular | 4G LTE, internal antenna, 1× mini SIM-2FF |
| GNSS | GPS/GLONASS/QZSS/SBAS, internal antenna, -161 dBm tracking sensitivity |
| Power Supply | 802.3 af PoE or 6~12 V DC via M12 connector |
| Power Consumption | Typical 3.6 W, Max 4.8 W |
| Ingress Protection | IP67 |
| Operating Temperature | -40°C to +70°C (reduced cellular performance above 60°C) |
| Dimensions | 240 × 164 × 90.9 mm |
| Weight | 1463 g |
| Installation | Wall or pole mounting |
Application scenarios
The UG67 connects thousands of sensors across farms, factories, buildings, and cities—enabling smart agriculture, automated metering, industrial monitoring, and asset tracking with reliable 15 km coverage.
Application Case
Traditional agriculture faces critical inefficiencies: excessive water waste from uneven irrigation distribution, crop damage caused by imprecise watering practices, and labor-intensive manual monitoring that lacks real-time visibility for timely decision-making.
Transform irrigation from guesswork to precision:
• UC501 monitors soil conditions in real time
• UC511 and UC300 automate valve and pump control
• UG67 gateway connects all devices to the cloud
• Mobile app enables remote monitoring and instant control
Result: Less water waste, higher yields, complete farm visibility.
