BAC Series BTL-Certified Multi-Protocol BACnet Gateway
Convert 500+ industrial protocols to standard BACnet, enabling seamless integration of non-BACnet devices into mainstream building automation systems—no equipment replacement, plug and play. Ideal for HVAC, energy management, and smart building retrofits.
Product Features
• Protocol Conversion: 500+ industrial protocols → BACnet IP/MS/TP + OPC UA
• System Compatibility: BTL Gold Certified, seamless integration with Metasys/EBI/Desigo CC/EBO
• Deployment Speed: 256 points in 10 mins, 1024 points in 20 mins
• Hardware Reliability: -20℃~+70℃ wide temperature, isolated RS485, DIN rail mounting
• Flexible Scaling: 256~2048 dynamic points, 1~4 serial ports configurable
• Remote O&M: Built-in web server, real-time data monitoring + online diagnostics
Purchase Ways
Selection and Comparison
| Hardware Parameter Comparison Table | ||||
|---|---|---|---|---|
| Parameter | BAC1001-ARM | BAC1002-ARM | BAC2004-ARM | BAC2004-A9 |
| Support Points | 256 | 512 | 1024 | 2048 |
| Ethernet Ports | 1×10/100M | 2×10/100/1000M | ||
| RS485 Serial Ports | 1 (isolated) | 2 (isolated) | 4 (isolated) | |
| CPU | 750MHz | 1GHz | ||
| RAM/Storage | 64MB/32MB | 512MB/4GB | ||
| Power Consumption | 6W | 8W | ||
| Dimensions | 119×55×33mm | 120×107×27mm | ||
| Weight | 200g | 210g | 300g | |
| Mounting | DIN rail/Wall mount | DIN rail | ||
| Common Core Parameters | |
|---|---|
| Parameter | Value |
| Power Supply | AC/DC 12-24V |
| Operating Temperature | -20℃~+70℃ (Working) / -40℃~+85℃ (Storage & Transportation) |
| Operating Humidity | 20%~90% Non-condensing |
| Material | Galvanized Steel Sheet |
| Certification | BTL, CE |
Application scenarios
Integrates diverse building systems into unified BACnet networks—HVAC (air handling units, fresh air systems, thermostats), energy management (electricity/water/gas meters, UPS), elevator monitoring (controllers, escalators, access control), smart lighting (controllers, dimmers, sensors), fire alarm systems (panels, smoke detectors, manual call points), and industrial equipment (PLCs, DDCs, VFDs, sensors).
