| Application Scenario |
For diversified indoor scenarios to connect multiple equipments through comprehensive interfaces |
For diversified outdoor scenarios to connect multiple equipments through comprehensive interfaces |
For diversified outdoor scenarios to connect multiple equipments through comprehensive interfaces |
For multiple outdoor scenarios, especially effective for smart irrigation. |
For multiple outdoor scenarios, especially effective for smart irrigation. |
| LoRaWAN® Availability |
√ |
√ |
√ |
√ |
√ |
| Frequency Band |
CN470 / IN865 / EU868 / RU864 / US915 / AU915 / KR920 / AS923-1&2&3&4 |
CN470 / IN865 / EU868 / RU864 / US915 / AU915 / KR920 / AS923-1&2&3&4 |
CN470 / IN865 / EU868 / RU864 / US915 / AU915 / KR920 / AS923-1&2&3&4 |
CN470 / IN865 / EU868 / RU864 / US915 / AU915 / KR920 / AS923-1&2&3&4 |
CN470 / IN865 / EU868 / RU864 / US915 / AU915 / KR920 / AS923-1&2&3&4 |
| Antenna |
External Antenna |
Internal Antenna or External Antenna (Hardware Optional) |
Internal Antenna or External Antenna (Hardware Optional) |
Internal Antenna or External Antenna (Hardware Optional) |
Internal Antenna or External Antenna (Hardware Optional) |
| Sensitivity |
-137 dBm Sensitivity @300bps |
-137 dBm Sensitivity @300bps |
-137 dBm Sensitivity @300bps |
-137 dBm Sensitivity @300bps |
-137 dBm Sensitivity @300bps |
| Tx Power |
16dBm (868 MHz)/20dBm (915 MHz)/19dBm (470 MHz) |
16dBm (868 MHz)/20dBm (915 MHz)/19dBm (470 MHz) |
16dBm (868 MHz)/20dBm (915 MHz)/19dBm (470 MHz) |
16dBm (868 MHz)/20dBm (915 MHz)/19dBm (470 MHz) |
16dBm (868 MHz)/20dBm (915 MHz)/19dBm (470 MHz) |
| Protocol |
LoRaWAN® V1.0.2 or V1.0.3 |
LoRaWAN® V1.0.2 or V1.0.3 |
LoRaWAN® V1.0.2 or V1.0.3 |
LoRaWAN® V1.0.2 or V1.0.3 |
LoRaWAN® V1.0.2 or V1.0.3 |
| Work Mode |
OTAA/ABP Class C |
OTAA/ABP Class A, Class C |
OTAA/ABP Class A |
OTAA/ABP Class A, Class B, Class C, Class C to B |
OTAA/ABP Class A, Class B |
| Cellular Availability |
Optional |
N/A |
N/A |
N/A |
N/A |
| Interface Type |
Terminal Block |
M12 A-Coded Male Connector |
M12 A-Coded Male Connector |
M12 A-Coded Male Connector |
M12 A-Coded Male Connector |
| GPIO |
N/A |
2 × GPIO, 0-3.3VDC (DI, DO Switchable) |
2 × GPIO, 0-3.3VDC (DI, DO Switchable) |
N/A |
N/A |
| DI |
4 × DI, 3-24VDC Opto-Isolated Inputs |
N/A |
N/A |
2 × DI, Dry Contacts |
2 × DI, Dry Contacts |
| DO |
2 × Relay Outputs |
N/A |
N/A |
N/A |
N/A |
| Pulse Support(DI) |
√ |
√ |
√ |
√ |
√ |
| Analog Input |
2 × 4-20mA + 2 × 0-10V |
2 × 4-20mA or 2 × 0-10V (Switchable) |
2 × 4-20mA or 2 × 0-10V (Switchable) |
N/A |
N/A |
| PT100 |
2 × PT100 RTD Inputs |
N/A |
N/A |
N/A |
N/A |
| Serial Port |
1 × RS232 + 1 × RS485 |
1 × RS232 or RS485 (Switchable) |
1 × RS232 or RS485 (Switchable) |
N/A |
N/A |
| SDI-12 |
N/A |
1 × SDI12(V1.4) |
1 × SDI12(V1.4) |
N/A |
N/A |
| Power Output |
N/A |
2 × 3.3 V, 2 × 5/9/12 V(Switchable) to Supply Power to Sensors |
2 × 3.3 V, 2 × 5/9/12 V(Switchable) to Supply Power to Sensors |
N/A |
N/A |
| Solenoid Interface |
N/A |
N/A |
N/A |
2 × DC 12V to Control 2-Wire Latching Solenoid |
2 × DC 12V to Control 2-Wire Latching Solenoid |
| DC |
5-24 VDC by Terminal Block |
5-24VDC by M12 Connector |
5-24VDC by M12 Connector |
5-24VDC by M12 Connector |
5-24VDC by M12 Connector |
| Battery |
N/A |
5100 mAh Chargeable Batteries |
27000 mAh Replaceable Batteries |
5100 mAh Chargeable Batteries |
27000 mAh Replaceable Batteries |
| Solar Powered |
N/A |
Solar Powered (6V, 1.7W) |
N/A |
Solar Powered (6V, 1.7W) |
N/A |
| USB |
1 × Type-C (Internal) for Debug and Power Supply |
1 × Type-C (Internal) for Debug and Power Supply |
1 × Type-C (Internal) for Debug and Power Supply |
1 × Type-C (Internal) for Debug and Power Supply |
1 × Type-C (Internal) for Debug and Power Supply |
| NFC |
N/A |
√ |
√ |
√ |
√ |
| Multicast |
N/A |
√ |
N/A |
√ |
√ |
| Milesight D2D |
√ |
N/A |
N/A |
√ |
N/A |
| Data Storage & Retransmission |
√ |
√ |
√ |
√ |
√ |
| IF-THEN Commands |
√ |
√ |
√ |
N/A |
N/A |
| Solenoid Local Schedule |
N/A |
N/A |
N/A |
√ |
√ |
| Protection |
IP30 |
IP68 (1m underwater, 7 days) |
IP68 (1m underwater, 7 days) |
IP68 (1m underwater, 7 days) |
IP68 (1m underwater, 7 days) |
| Size (mm) |
90 x 70 x 22 |
116 x 116 x 45.5 |
116 x 116 x 45.5 |
116 x 116 x 45.5 |
116 x 116 x 45.5 |
